Polymer GypTec Fasteners 3 in. to 10 in. Glass-Filled Nylon Insulation Fasteners
$345.00 /carton
$0.69 per piece · 500 per carton
Orders start at $399. Combine any items to reach it.
Sold by the carton of 500, as the chosen option states. We round up and set the quantity for you.
- 1 carton · 500 pieces
- $345.00
- Standard delivery
- $49.99 per order
- Sales tax
- Added at checkout
All orders are subject to approval.
You're not charged until your order is approved and ready to ship. Cancel free before then.
Standard delivery$49.99
Per order, added in your cart. We deliver to the 48 contiguous states.
Availability confirmed by the desk at approval, with your delivery date. Shipping policy · Returns
Goes with
Carlisle · Fasteners
Details & specifications.
From the maker · Carlisle’s description
Carlisle Polymer GypTec Fasteners are glass-filled nylon auger fasteners with a 1 in. head, made to secure insulation and single-ply membrane to gypsum and cementitious wood fiber decks. This page offers 3 in. to 10 in. lengths in cartons of 250 or 500. A 1/4 in. square drive enables fast installation, and lengths pair with deck and insulation thicknesses per the project spec.
Coverage & How Much You Need
Coverage depends on the insulation fastening pattern per the roof design. Common practice is one fastener per specified square footage of insulation board, so calculate carton counts from board size and fastener density specified for the wind zone.
Fit and Compatibility
Designed for gypsum and cementitious wood fiber decks under Carlisle single-ply membrane and insulation systems. Compatible plates lock onto the 1 in. head via the fastener tabs; plates are specified and ordered separately per the system.
- SKU
- CARF4PG
- Drive
- Internal 1/4 in. (6 mm) square drive
- Material
- Glass-filled nylon
- Brand
- Carlisle
- Size
- 4" 500/Carton
As listed for this product. Some values differ by option.
- Sell unit
- 1 carton (500 for lengths up to 6.5 in.; 250 for 8-10 in.)
- Product line
- Carlisle Polymer GypTec Fasteners
- Head size
- 1 in. (25 mm)
- Available sizes
- 3", 3.5", 4", 5", 6", 6.5", 8", 9", 10" (full range 2-1/2" to 12" / 60 to 305 mm)
- Thread design
- Wide buttress thread with large root diameter
- Intended use
- Securing insulation and single-ply membrane to gypsum and cementitious wood fiber decks
- Approvals
- FM approved for insulation attachment
- Pack quantity
- 500 per carton (3, 3.5, 4, 5, 6, 6.5 in. lengths); 250 per carton (8, 9, 10 in. lengths)
Key features
- Glass-Filled Nylon: Made from glass-filled nylon for high tensile strength with no corrosion, thermal bridging, or condensation.
- 1 in. Head: 1 in. (25 mm) head with tabs that lock the plate to the fastener head.
- Square Drive: Internal 1/4 in. (6 mm) square drive ensures fast, easy installation.
- Length Range: Available in 2-1/2 in. to 12 in. (60 to 305 mm) lengths; this page lists 3, 3.5, 4, 5, 6, 6.5, 8, 9, and 10 in.
Specifications are provided by the manufacturer. Brand names are trademarks of their owners.
Guide
Choosing the fastener
- 1
Outdoors and treated lumber
Use hot-dip galvanized, stainless or exterior-coated fasteners, and follow the board maker’s fastener recommendation.
- 2
Price per piece
The pack price divided by the pieces in the pack, both as listed.
- 3
Drive
Star (Torx), square, Phillips or hex, as the listing states. Match the bit you carry.
They are designed for gypsum and cementitious wood fiber decks.
