Wilsonart Castle Oak 7928 High-Pressure Laminate Sheets
Regular price $175.26Orders start at $399 — combine any items to reach the minimum. Learn more
Wilsonart Castle Oak 7928 High-Pressure Laminate Sheets
Wilsonart Castle Oak 7928 is a relatively straight-grained oak laminate with partial half cathedrals, subtle planking and a natural color with very subtle red, yellow and green undertones. The page offers 47 variants in fine velvet and matte finishes across standard, vertical, postform, Chemsurf, compact and fire-rated grades. One sheet per order unit; special order with roughly a 2-week lead time.
Key Features:
- Natural oak look: Straight-grained oak with partial half cathedrals and subtle planking.
- Undertoned color: Natural overall color with very subtle red, yellow and green undertones.
- Chemsurf option: 390 Chemsurf HPL is listed for chemical-resistant surfacing.
- Compact panels: 1/2 in. Compact HPL panels are available in four sizes for self-supporting use.
- Fire-rated grades: Fire Rated Vertical, Postform and Standard grades are listed in 60 Matte Finish.
- Two finishes: Offered in 38 Fine Velvet Finish and 60 Matte Finish.
- Special order: Non-standard special-order design; allow approximately 2 weeks if not stocked locally.
Specifications Table:
| Specification | Details |
|---|---|
| Brand | Wilsonart |
| Manufacturer model | 7928 |
| Sell unit | 1 sheet |
| Design number | 7928 |
| Design name | Castle Oak |
| Available finishes | 38 Fine Velvet Finish; 60 Matte Finish |
| Available grades | 107 Standard HPL; 335 Vertical HPL; 350 Postform HPL; 390 Chemsurf HPL; 568 Compact HPL; 604 Fire Rated Vertical HPL; 605 Fire Rated Postform HPL; 607 Fire Rated Standard HPL |
| Available sheet sizes | 14 sizes, from 30" x 96" to 60" x 144", including 36" x 96" and 1/2" compact panels in 48" x 96", 60" x 96", 60" x 120" and 60" x 144" |
| Thickness | 1/2 in. (Compact HPL items only) |
| Surface / pattern | Straight-grained oak with partial half cathedrals and subtle planking; natural color with subtle red, yellow and green undertones |
| Recommended use | Standard for horizontal surfaces, Postform for rolled edges, Vertical for cabinet sides and walls, Compact for self-supporting panels, Chemsurf for chemical resistance, Fire Rated for code-required interiors |
| Number of variants | 47 |
Fit and Compatibility:
Bonds with contact adhesive to particleboard, MDF or plywood; compact panels are self-supporting. Adhesive, substrate and matching edge banding are sold separately. Use backer sheets behind horizontal grades to keep panels flat; for high-wear needs not listed here, compare related Wilsonart designs.
Frequently Asked Questions (FAQ):
Q: What is included?
A: One sheet of Wilsonart 7928 Castle Oak in the finish, grade and size selected; adhesive and substrate are not included.
Q: Which grade for countertops?
A: Use 350 Postform HPL for rolled edges or 107 Standard HPL for flat horizontal layup on particleboard.
Q: Is there a chemical-resistant option?
A: Yes, 390 Chemsurf HPL is listed in 60 Matte Finish in 48 in. x 96 in. and 60 in. x 144 in.
Q: What thickness are compact panels?
A: Compact HPL items are printed at 1/2 in., in sizes from 48 in. x 96 in. up to 60 in. x 144 in.
Q: How long is the lead time?
A: This is a special-order design; allow approximately 2 weeks if not stocked locally, with a 24-hour window to cancel.
Q: Can I get vertical-grade sheets in small sizes?
A: Yes, vertical grade in 38 Fine Velvet is listed from 30 in. x 96 in. up to 60 in. x 144 in., plus a 48 in. x 120 in. option.
Expert Verdict — Reviewed by the SuperArbor Pro Desk
Castle Oak's straight grain makes seams easier to hide on long runs; keep grain direction consistent and plan seams away from sinks. For countertop work, pair 350 Postform with a stable particleboard core and a balancing backer sheet. The 1/2 in. compact panels are heavy, so schedule extra help or a panel lift for 60 in. x 144 in. pieces.
Large laminate sheets are heavy and awkward; use two-person handling or panel lifters, and wear gloves and eye protection when cutting.
Order Wilsonart Castle Oak 7928 laminate in the finish, grade and size for your next build.
