Wilsonart 4937 Pinball Geometric Laminate, Compact, Chemsurf, Standard, Vertical and Postform Grades, Multiple Sizes
Regular price $1,056.90Orders start at $399 — combine any items to reach the minimum. Learn more
Wilsonart 4937 Pinball Geometric Laminate, Compact, Chemsurf, Standard, Vertical and Postform Grades, Multiple Sizes
Wilsonart 4937 Pinball is a multilayer geometric laminate on an off-white background, with bright white accents and grey lines creating layered geometries. Available in fifteen variants across standard, vertical, postforming, Chemsurf and 1/2 in. compact grades. Each order is one sheet in the finish, grade and size selected.
Key Features:
- Geometric design: Bright white accents and grey lines on an off-white background create a multilayer design of geometries.
- Wide grade range: Offered in 107 Standard, 335 Vertical, 350 Postform, 390 Chemsurf and 568 Compact HPL grades.
- Self-supporting panels: 1/2 in. compact grade panels in 60 in. widths are suitable for self-supporting applications such as partitions and toilet dividers.
- Chemical-resistant option: The 390 Chemsurf grade is offered for lab and work surface applications requiring chemical resistance.
- Finish choices: Available in 38 Fine Velvet and 60 Matte finishes.
- Special order: If not stocked locally, allow approximately a 2-week lead time for delivery.
Specifications Table:
| Specification | Details |
|---|---|
| Brand | Wilsonart |
| Manufacturer model | 4937 |
| Sell unit | 1 sheet (compact: 1 panel) |
| Design number | 4937 |
| Design name | Pinball |
| Material | High-pressure laminate (HPL); compact panels 1/2 in. thick |
| Surface / pattern | Multilayer geometric design; off-white background with bright white accents and grey lines |
| Available finishes | ['38 Fine Velvet Finish', '60 Matte Finish'] |
| Available grades | ['107 Standard HPL', '335 Vertical HPL', '350 Postform HPL', '390 Chemsurf HPL', '568 Compact HPL'] |
| Available sheet sizes | ['30" x 96"', '30" x 144"', '36" x 96"', '48" x 96"', '48" x 120"', '48" x 144"', '60" x 96"', '60" x 120"', '60" x 144"', '1/2" x 60" x 120" (compact)', '1/2" x 60" x 144" (compact)'] |
| Thickness | 1/2 in. (compact grade panels only, as printed) |
| Recommended use | Standard grade for horizontal surfaces; vertical grade for cabinet sides and walls; postforming for rolled edges; Chemsurf for chemical-resistant work surfaces; compact for self-supporting panels |
Coverage & How Much You Need:
Standard sheets cover up to 60 sq. ft. (60 in. x 144 in.) and compact panels up to the same in 1/2 in. thickness. Size each job by selecting a sheet larger than the finished surface so seams can fall in low-visibility areas.
Fit and Compatibility:
Bond standard, vertical and postform sheets to particleboard or MDF with contact adhesive; compact panels are self-supporting and can be screwed or routed without a substrate. Backer sheets are recommended on the underside of bonded panels; Chemsurf is intended where chemical resistance is required.
Frequently Asked Questions (FAQ):
Q: What finishes and grades are available?
A: The design comes in 38 Fine Velvet and 60 Matte finishes across 107 Standard, 335 Vertical, 350 Postform, 390 Chemsurf and 568 Compact HPL grades.
Q: Are compact panels a different thickness?
A: Yes, 568 Compact grade items are printed at 1/2 in. thick in 60 in. x 120 in. and 60 in. x 144 in. sizes.
Q: Do I need a substrate?
A: Standard, vertical, postform and Chemsurf sheets must be bonded to a stable core such as particleboard or MDF; 1/2 in. compact panels are self-supporting and typically need no substrate.
Q: What adhesive should I use?
A: Use contact adhesive on both the laminate and the substrate for sheet lamination; follow the adhesive manufacturer's coverage and open-time guidance.
Q: How is this grade different from the 4937K version?
A: This 4937 page offers many finishes, grades and sizes including compact and Chemsurf; the K-numbered page is a single postforming item.
Q: What is the lead time?
A: It is a special-order design; allow approximately 2 weeks if not stocked locally.
Expert Verdict — Reviewed by the SuperArbor Pro Desk
Pinball reads as a linear geometric, so keep sheet orientation consistent across adjacent tops and splash. Use 350 Postform for rolled countertop edges, 335 Vertical for cabinet ends, and 390 Chemsurf where lab-grade chemical resistance is needed. Compact panels machine cleanly for square-edge details but are heavy; plan two-person handling for 60 in. x 144 in. panels.
Compact panels are heavy and brittle at cut edges; support the full sheet during cutting and wear eye and respiratory protection.
Choose your Wilsonart Pinball laminate in the grade, finish and sheet size for your countertop or panel project.
