Wilsonart 4810 Titanium EV High-Pressure Laminate Sheets - Matte Grey Fiber Design, Seven Grades Including Chemsurf and Compact
Regular price $242.22Orders start at $399 — combine any items to reach the minimum. Learn more
Wilsonart 4810 Titanium EV High-Pressure Laminate Sheets - Matte Grey Fiber Design, Seven Grades Including Chemsurf and Compact
Wilsonart Titanium EV (4810) is a matte high-pressure laminate with a small-scale fiber design: a light grey background with hints of taupe covered in small off-white fibers. It is offered in standard, high wear, vertical, postforming, chemical-resistant, compact and fire-rated grades across 12 sheet sizes. Each variant is sold as 1 sheet or panel.
Key Features:
- Fine fiber texture: A light grey background with taupe hints is covered by a layer of small off-white fibers.
- Matte finish: All variants on this page are produced in 60 Matte Finish.
- Seven grades: Available in 107 Standard, 107 Standard High Wear, 335 Vertical, 350 Postform, 390 Chemsurf, 568 Compact and 607 Fire Rated Standard HPL.
- Lab-capable grade: 390 Chemsurf HPL is the chemical-resistant grade for laboratory and workroom surfaces.
- Self-supporting panel: The 1/2 in. 568 Compact HPL variants form self-supporting panels without a substrate.
- Fire-rated option: 607 Fire Rated Standard HPL is available for code-required interiors.
- Special order: A non-standard option; allow approximately a 2-week lead time if not stocked locally.
Specifications Table:
| Specification | Details |
|---|---|
| Brand | Wilsonart |
| Manufacturer model | 4810 |
| Sell unit | 1 sheet (compact: 1 panel) |
| Design number | 4810 |
| Design name | Titanium EV |
| Material | High-pressure laminate (HPL); compact variants 1/2 in. thick |
| Surface / pattern | Small-scale fiber design, light grey with taupe hints and small off-white fibers |
| Available finishes | 60 Matte Finish |
| Available grades | 107 Standard HPL (general-purpose horizontal), 107 Standard High Wear HPL (heavy-use horizontal), 335 Vertical HPL (cabinet sides and walls), 350 Postform HPL (rolled countertop edges), 390 Chemsurf HPL (chemical-resistant), 568 Compact HPL (self-supporting panels, 1/2 in.), 607 Fire Rated Standard HPL |
| Available sheet sizes | 12 sizes: 1/2 in. x 60 in. x 120 in., 1/2 in. x 60 in. x 144 in., 30 in. x 96 in., 30 in. x 120 in., 30 in. x 144 in., 36 in. x 96 in., 48 in. x 96 in., 48 in. x 120 in., 48 in. x 144 in., 60 in. x 96 in., 60 in. x 120 in., 60 in. x 144 in. |
| Recommended use | Horizontal counters, postformed edges, vertical surfaces, chemical-resistant or fire-rated interiors, depending on grade |
Fit and Compatibility:
Bond standard, vertical, postforming, fire-rated and Chemsurf grades to approved substrates such as particleboard or MDF with contact adhesive, with a backer sheet on the reverse of countertops. The 1/2 in. compact panels are self-supporting and can be used without a substrate. Adhesives, backer sheets and edge banding are sold separately.
Frequently Asked Questions (FAQ):
Q: What is included with the order?
A: One laminate sheet or 1/2 in. compact panel in the grade and size you select; adhesive, substrate and backer sheets are sold separately.
Q: What does the design look like?
A: It is a small-scale fiber pattern: a light grey background with hints of taupe, covered by a layer of small off-white fibers.
Q: Which grade is best for a busy commercial counter?
A: The 107 Standard High Wear HPL grade offers a more durable surface for heavy-use horizontal surfaces, in the same matte finish.
Q: Is there a chemical-resistant option?
A: Yes, the 390 Chemsurf HPL grade is the chemical-resistant option for laboratory surfaces.
Q: When would I choose compact?
A: The 568 Compact HPL at 1/2 in. thick is self-supporting, suited to panels, partitions and counters built without a full substrate.
Q: How long is the lead time?
A: It is a special-order, non-standard option; allow approximately a 2-week lead time if not stocked locally.
Expert Verdict — Reviewed by the SuperArbor Pro Desk
Titanium EV is a classic neutral tech-fabric look that hides wear and coordinates with nearly any cabinet color, which is why shops keep it on hand for commercial work. Order the 60 in. wide postform sheets for standard-depth tops and stay within one sheet length to avoid mid-run seams. Use Chemsurf or fire-rated grades only where the specification calls for them, and balance all horizontal tops with a backer sheet.
Sheets and compact panels are heavy with sharp trimmed edges; carry with two people and wear gloves and eye protection when cutting.
Order Wilsonart Titanium EV laminate in the grade and sheet size your project calls for.
