200 Amp Double-Pole Circuit Breaker
200 A2-poleStandard
$270.98 each
Orders start at $399. Combine any items to reach it.
- 1 breaker
- $270.98
- Standard delivery
- $49.99 per order
- Sales tax
- Added at checkout
All orders are subject to approval.
You're not charged until your order is approved and ready to ship. Cancel free before then.
Standard delivery$49.99
Per order, added in your cart. We deliver to the 48 contiguous states.
Availability confirmed by the desk at approval, with your delivery date. Shipping policy · Returns
Complete the panel
Siemens · Electrical
Details & specifications.
From the maker · Siemens’s description
Ensure the safety and reliability of your electrical system with the Siemens 200 Amp Double-Pole Circuit Breaker. Designed for use in Siemens panels that accept Type QPPH Main Breakers, this circuit breaker provides robust overload and short-circuit protection. With its advanced thermal magnetic trip unit, it accommodates both residential and multi-family applications.
Please check the Product Data Sheet Here
Shield Your Space with Seamless Security
Transform your power distribution system with Siemens' impeccably constructed circuit breaker, blending functionality with style. The slender, efficient design ensures minimal space disruption while delivering maximum protection. Position this circuit breaker in a clean, organized control panel to exemplify its subtle elegance. Embrace this essential component for its steadfast reliability, securing your home's electric circuit with finesse.
Upgrade your electrical system's safety and efficiency with the Siemens 200 Amp Circuit Breaker—purchase today for peace of mind tomorrow.
- SKU
- Q2200BH
- UPC
- 0783643148864
- Amps
- 200 A
- Poles
- 2-pole
- Protection
- Standard
- Interrupt rating
- 22 kA
- Voltage
- 120/240 V
- Mounting
- Plug-On
- Brand
- Siemens
- Breaker Type
- Standard
- Connection Type
- Non-Neutral
- Interruption Type
- Standard Trip
- Maximum Amperage (A)
- 200 A
- Number of Poles
- Double
- Pack Size
- 1
- Product Weight (lb.)
- 2.125 lb
- Trip Unit
- Thermal Magnetic
- Certifications and Listings
- UL Listed
- Manufacturer Warranty
- Lifetime
- Product Depth (in.)
- 12.8 in
- Product Height (in.)
- 3.70 in
- Product Width (in.)
- 4.50 in
- Full product name
- Siemens 200 Amp Double-Pole 22kA Type QPPH Circuit Breaker
Key features
- Side Wired Design: Saves wiring space eliminating cumbersome bends.
- Single Right-Hand Bend Wiring: Reduces time and material usage.
- High Interrupting Capacity: Provides 22 kA interrupting rating.
- Compatibility: Accepts a range of wire types including #3/0 AWG Cu or 250kcmil AWG Al.
- UL Listed: Meets safety and performance standards.
Specifications are provided by the manufacturer. Brand names are trademarks of their owners.
Guide
Before you buy a breaker
- 1
Match the panel
Find the brand and series on the label inside the panel door. Homeline and QO are both Square D, and they do not interchange.
- 2
Match the wire
The breaker protects the wire. For copper: 14 AWG on 15 A, 12 AWG on 20 A, 10 AWG on 30 A.
- 3
Protection
Standard, AFCI (arc fault), GFCI (ground fault) or dual function. Your local code says which circuits need which.
- 4
Tandem and quad
Two circuits in one space, only in the slots the panel label allows.
Installation involves carefully plugging the breaker into the appropriate Siemens panel. Always ensure power is off and refer to a certified electrician for safe installation.
