Rev-A-Shelf 448 Series Ball-Bearing Base Cabinet Pull-Out Organizer, 5 in. and 8 in. Widths, Natural Maple with Soft-Close Slides
Regular price $252.54Orders start at $399 — combine any items to reach the minimum. Learn more
Rev-A-Shelf 448 Series Ball-Bearing Base Cabinet Pull-Out Organizer, 5 in. and 8 in. Widths, Natural Maple with Soft-Close Slides
The Rev-A-Shelf 448 BB series is a wood base cabinet pull-out organizer for 12 in. full face frame base cabinets, made of natural maple with a semi-gloss finish. Each unit includes adjustable shelves with chrome rails, door-mount hardware and ball-bearing soft-close slides. Available in 5 in. and 8 in. widths in a 4-compartment configuration.
Key Features:
- Soft-close operation: Ball-bearing slides with soft-close action let the organizer glide out and close gently.
- Adjustable shelving: Adjustable shelves with chrome rails let you reconfigure storage height to fit your items.
- Natural maple wood: Constructed of wood with a natural maple semi-gloss finish that complements cabinet interiors.
- Four compartments: The 4-compartment layout separates trays, pans and lids for organized access.
- Door-mount design: Floor-mounted unit with door-mount hardware attaches the cabinet door to the pull-out.
- Two width options: Offered in 5 in. and 8 in. widths to fit narrow filler pull-outs or wider base cabinets.
Specifications Table:
| Specification | Details |
|---|---|
| Brand | Rev-A-Shelf |
| Sell unit | 1 set |
| Model / series | 448 BB Series |
| Available sizes | 5 in. W x 21-21/32 in. D x 25-1/2 - 29-1/2 in. H; 8 in. W x 21-21/32 in. D x 25-1/2 - 29-1/2 in. H |
| Available finishes | Natural Maple / Semi-Gloss |
| Configuration | 4-Compartment |
| Material | Wood |
| Finish / colour | Natural Maple / Semi-Gloss |
| Cabinet opening (as printed) | 25-3/4 in. H x 8-1/2 in. W x 22 in. D |
| Intended cabinet | 12 in. full face frame base cabinet |
| Mounting | Floor mount with door-mount hardware |
| Slide type | Ball bearing, soft-close |
| Includes | Adjustable shelves with chrome rails, door-mount hardware |
| Pack quantity | 16 per box |
Fit and Compatibility:
Designed for 12 in. full face frame base cabinets with the printed 25-3/4 in. H x 8-1/2 in. W x 22 in. D opening. Door-mount hardware is included; the door panel attaches to the pull-out frame. Measure your opening before ordering, as the 5 in. and 8 in. widths require matching opening widths.
Frequently Asked Questions (FAQ):
Q: What is included with the pull-out?
A: Each unit includes adjustable shelves with chrome rails, door-mount hardware and ball-bearing soft-close slides.
Q: What size cabinet does it fit?
A: It is made for a 12 in. full face frame base cabinet with a 25-3/4 in. H x 8-1/2 in. W x 22 in. D opening.
Q: Which width should I choose?
A: Choose the 5 in. width for narrow filler pull-outs and the 8 in. width for standard narrow base cabinets, matching your measured opening.
Q: How do I install it?
A: Mount the unit to the cabinet floor, attach the door to the organizer with the included door-mount hardware, and confirm the opening height between 25-1/2 in. and 29-1/2 in.
Q: Is the finish real wood?
A: Yes, the organizer is constructed of wood with a natural maple semi-gloss finish.
Q: Is soft-close included?
A: Yes, the 448 BB uses ball-bearing slides with soft-close action.
Expert Verdict — Reviewed by the SuperArbor Pro Desk
As an installer, I measure the actual opening, not the door, before ordering: this 448 series needs the printed opening and clears a full face frame. The adjustable chrome-railed shelves are the reason to pick this line over fixed trays, since shelf positions can be tuned to tall stock pots or baking sheets. Pick the 8 in. model when the cabinet allows it; the 5 in. unit is best reserved for true filler cabinets. Attach the door after leveling the base so reveal gaps stay even.
Secure the unit to the cabinet floor and fully engage the slides before loading; an unsecured pull-out can tip when extended.
Order the Rev-A-Shelf 448 BB base cabinet pull-out organizer to turn a narrow base cabinet into organized, soft-close storage.
