NORTON DOOR CONTROLS 7570 Series Heavy Duty Door Closer - Bronze
Regular price $1,003.47Heavy Duty Bronze Door Closer
The NORTON DOOR CONTROLS 7570 Series Heavy Duty Door Closer is engineered for demanding commercial applications. Crafted with an aluminum body and a sleek, dark bronze finish, this door closer ensures both durability and aesthetic appeal for interior and exterior doors.
Key Features:
- Sleek Appearance: The parallel arm folds beneath the door frame for a clean, unobtrusive look.
- Adjustable Backcheck: Features adjustable cushioning for smooth, controlled door movement.
- Heavy Duty Performance: Grade 1 performance withstanding up to 25 million cycles, suitable for high-traffic areas.
- Versatile Compatibility: Non-handed design fits doors up to 54 inches wide and supports weights up to 250 lbs.
- Fire Rated: UL10C certified for 3-hour fire doors, providing enhanced safety.
Specifications Table:
| Specification | Details |
|---|---|
| Manufacturer Part Number | UNI7570 X 690 LH |
| Brand | NORTON DOOR CONTROLS |
| Closer Mounting Type | Parallel |
| Closer Series | 7570 |
| Closer Stop Type | Spring |
| Closer Type | Non-Hold Open |
| Color | Dark Bronze |
| Compatible with Brand | NORTON RIXSON |
| Display Qty | 1 |
| Display Sell UOM | EA |
| Max Door Opening Angle | 110 ° |
| Features | Adjustable Backcheck Cushioning and Positioning |
| Finish | Bronze |
| Fire Rating | 3 hr |
| Housing Depth | 2-3/16 in |
| Housing Height | 3-3/4 in |
| Energy Source | Hydraulic |
| Includes | Deep Drawn Steel Cover |
| Door Width Campatibility | 54 in |
| Location Use | Interior/Exterior |
| Standards | UL and cUL Listed |
| UL Fire Rating | UL10C |
| Spring Type | Adjustable |
| Height Between Mounting Holes | 2-3/8 in |
| Spring Size - Minimum | 1 |
| Material | Aluminum |
| Door Weight - Maximum | 250 lb |
| Exterior Door Width - Maximum | 48 in |
| Product Type | Door Closer |
| Spring Size | 6 |
| Arm Type | Parallel |
| Closer Cycles | 25,000,000 |
| Hand Orientation | Non-Handed |
| Housing Length | 13-5/8 in |
| Operation Style | Manual |
| Performance Duty Rating | 1 |
| Length Between Mounting Holes | 6-3/4 in |
| Ligature Resistance | Not Ligature-Resistant |
| ADA Compliant | Yes |
| Performance Rating | Grade 1 - Heavy Duty |
| Finish C | Dark Bronze Painted ; Aluminum ; Dark Bronze |
Frequently Asked Questions (FAQ):
Q: What door sizes can this closer accommodate?
A: This door closer is compatible with doors up to 54 inches wide and can handle a maximum door weight of 250 lbs.
Q: Is this door closer suitable for fire-rated doors?
A: Yes, it is UL10C certified for up to 3-hour fire doors, making it suitable for fire-rated applications.
Q: Does the closer come with installation instructions?
A: Yes, the closer includes detailed installation instructions and all necessary mounting hardware.
Q: Can this door closer be used outdoors?
A: Yes, the 7570 Series is suitable for both interior and exterior door operations.
Q: What maintenance is required for optimal performance?
A: Regular checks for proper function and lubrication of moving parts will ensure long-term performance.
Elevate Your Entrance with Subtle Efficiency
The NORTON 7570 Heavy Duty Door Closer seamlessly blends into any architectural style, transforming entryways with its understated elegance. Its bronze finish adds a touch of timeless sophistication to doors, enhancing both classic and modern spaces. Consider pairing this closer with complementary hardware for a cohesive look that underscores the grace of your design narrative. It's not just a functional necessity; it's an element of thoughtful design that embodies the art of refined living.
Upgrade to this NORTON Heavy Duty Door Closer today for a blend of functionality and style perfect for any project.
