Carlisle Sure-Seal EPDM Kleen FR Non-Reinforced Membrane, 45-90 mil, Black Roll with Optional Factory Tape
Regular price $1,965.00Orders start at $399 — combine any items to reach the minimum. Learn more
Carlisle Sure-Seal EPDM Kleen FR Non-Reinforced Membrane, 45-90 mil, Black Roll with Optional Factory Tape
Carlisle Sure-Seal EPDM Kleen FR is a fire-retardant, non-reinforced black EPDM roofing membrane for new single-ply construction and re-roofing. Rolls come in 45, 60 or 90 mil thicknesses, up to 10 ft wide and up to 100 ft long, with optional 3 in. or 6 in. factory-applied seam tape. Sold per roll.
Key Features:
- Fire retardant: Specially formulated to inhibit the spread of flame and meet or exceed code body testing criteria for fire-retardant roofing membranes.
- Proven weathering: Carlisle EPDM offers 50 years of proven performance and industry-leading weathering resistance, with 41,580 kJ/m² total radiant exposure without cracking or crazing.
- Hail resistant: 465% elongation and weathering resistance deliver superior hail damage resistance, rated UL 2218 Class 4.
- Cold-weather flexibility: Stays flexible in extreme cold down to -40°F (-40°C) and is the most dimensionally stable heat-resistant membrane.
- Factory tape options: Factory-Applied Tape seam technology, in 3 in. or 6 in. tape on selected rolls, enhances seam workmanship quality.
- Seamless extrusion: Extruded manufacturing produces seamless sheets that are UL Classified and FM Approved.
- Low environmental impact: EPA TRACI Life Cycle Assessment showed EPDM with the lowest global warming potential, acid rain impact and smog contribution versus TPO, PVC and modified bitumen.
Specifications Table:
| Specification | Details |
|---|---|
| Brand | Carlisle |
| Sell unit | 1 roll |
| Product line | Carlisle Sure-Seal EPDM Kleen FR Non-Reinforced Membrane |
| Available colors | Black |
| Available sizes | .045" x 10' x 50'; .045" x 10' x 100'; .060" x 10' x 25' (3" tape); .060" x 10' x 50'; .060" x 10' x 100'; .090" x 10' x 50'; .090" x 10' x 100'; selected sizes with 3" or 6" factory tape |
| Dimensions | Rolls up to 10 ft (3 m) wide and up to 100 ft (30 m) long |
| Thickness | 45 mil (1.14 mm), 60 mil (1.52 mm) or 90 mil (2.29 mm) |
| Material | Non-reinforced, fire-retardant EPDM rubber membrane |
| Color / finish | Black |
| Coverage per unit | Up to 1,000 sq ft per 10 ft x 100 ft roll |
| Wind / fire / impact rating as printed | Fire Retardant (FR); UL 2218 Class 4 hail; UL Classified; FM Approved |
| Approvals | UL Classified, FM Approved, UL 2218 Class 4 |
| Intended use | New single-ply roof construction and re-roofing applications |
Coverage & How Much You Need:
A 10 ft x 100 ft roll covers up to 1,000 sq ft and a 10 ft x 50 ft roll up to 500 sq ft before laps. Plan seams along the roll length and account for lap requirements when sizing the job.
Fit and Compatibility:
Works within Carlisle Sure-Seal EPDM systems with Carlisle's full line of pressure-sensitive flashing accessories, tapes, adhesives, sealants, insulations and cover boards, all manufactured by Carlisle. Dark EPDM is the recommended choice in colder climates.
Frequently Asked Questions (FAQ):
Q: What sizes are available?
A: Thicknesses of 45, 60 and 90 mil in rolls up to 10 ft wide and up to 100 ft long; some rolls include 3 in. or 6 in. factory-applied seam tape.
Q: What does FR mean on this membrane?
A: It is fire retardant: specially formulated to inhibit the spread of flame and meet or exceed code body testing criteria for fire-retardant roofing membranes.
Q: How much area does one roll cover?
A: A 10 ft x 100 ft roll covers up to about 1,000 sq ft and a 10 ft x 50 ft roll up to about 500 sq ft, less seam laps.
Q: Is it good in cold climates?
A: Yes, black EPDM stays flexible down to -40°F and is described as the smart choice for colder climates.
Q: How hail resistant is it?
A: Its 465% elongation and weathering resistance give superior hail resistance, with a UL 2218 Class 4 rating.
Q: Are seams taped?
A: Selected roll sizes include factory-applied 3 in. or 6 in. seam tape; other rolls use standard seaming methods.
Expert Verdict — Reviewed by the SuperArbor Pro Desk
Choose 60 mil as the workhorse thickness for most re-roofs and step up to 90 mil where traffic or hail exposure demands it; the FR formulation is the right pick where fire-retardant membrane is specified. The factory-tape versions speed seaming and improve workmanship consistency, so prefer them on large open fields. Black EPDM's heat absorption is an advantage in cold climates, and its low-temperature flexibility makes it forgiving to install year-round.
Heat-welded and adhesive applications require proper training, ventilation and rooftop fire-safety precautions; follow all manufacturer application instructions.
Order Carlisle Sure-Seal EPDM Kleen FR Non-Reinforced Membrane rolls for durable, fire-retardant single-ply roofing.
