Siemens · Electrical

100 Amp 2-Space 2-Circuit Small Main Breaker Indoor Load Center Enclosures Type EQ

2 spaces

$61.97 each

Orders start at $399. Combine any items to reach it.

Quantity
1 item
$61.97
Standard delivery
$49.99 per order
Sales tax
Added at checkout

All orders are subject to approval.

You're not charged until your order is approved and ready to ship. Cancel free before then.

Standard delivery$49.99

Per order, added in your cart. We deliver to the 48 contiguous states.

Availability confirmed by the desk at approval, with your delivery date. Shipping policy · Returns

Siemens · Electrical

Details & specifications.

From the maker · Siemens’s description

Siemens 100 Amp circuit breaker enclosure is indoor rated and provides space for two 1 in. spaces or four 1/2 in. spaces. The enclosure is provided with a surface mount cover. Breakers not included. This product is 1-Phase, 3-Wire SN. Circuit breaker enclosures range from 60 Amp to 225 Amp, indoor and outdoor model.

  • Suitable for use as service entrance equipment
  • Factory installed main breaker
  • Indoor rated
  • UL listed
SKU
302581407
Spaces
2
Mounting
Bolt On
Location
Indoor
Brand
Siemens
Item Weight
9.896
Number of Circuits
2
Maximum Amperage (amps)
100
Load Center Mounting Type
Flush, Surface
Voltage (volts)
120/240
Load Center Type
Main Breaker
Electrical Product Type
Load Center
Product Weight (lb.)
9.896
Indoor/Outdoor
Indoor
Phase Type
1 Phase
Load center width (in.)
17.7
Load center height (in.)
5.6
Load center depth (in.)
7.6
Certifications and Listings
UL Listed
Manufacturer Warranty
10 years

Specifications are provided by the manufacturer. Brand names are trademarks of their owners.

Guide

Before you buy a breaker

  1. 1

    Match the panel

    Find the brand and series on the label inside the panel door. Homeline and QO are both Square D, and they do not interchange.

  2. 2

    Match the wire

    The breaker protects the wire. For copper: 14 AWG on 15 A, 12 AWG on 20 A, 10 AWG on 30 A.

  3. 3

    Protection

    Standard, AFCI (arc fault), GFCI (ground fault) or dual function. Your local code says which circuits need which.

  4. 4

    Tandem and quad

    Two circuits in one space, only in the slots the panel label allows.
