Camelot Connect Smart Deadbolt (Bright Brass)

A Z‑Wave Plus enabled smart deadbolt with Camelot trim that delivers keyless convenience and premium security. Create and manage up to 30 access codes, monitor from anywhere when paired with a compatible hub, and enjoy easy, tool-only installation.

---

Key Features:

• Smart Home Ready: Z‑Wave Plus works with systems like SmartThings or Ring Alarm (hub required)
• Keyless Convenience: Up to 30 unique access codes with fingerprint-resistant, backlit touchscreen
• Premium Security: Built‑in alarm and metal construction; ANSI/BHMA Grade 1/AAA
• Easy Install: Fits standard doors; no hardwiring—installs in minutes with a screwdriver
• Reliable Power: Operates on 4 AA batteries with low-battery indicator and backup key

---

Specifications Table:

Specification	Details
Technology	Z‑Wave Plus enabled
Trim	Camelot
Finish	Satin Nickel shown; Bright Brass variant available
Access codes	30 code capacity
Programming	Pre-set unique 6-digit programming code; two pre-set unique 4-digit access codes
Power	Uses 4 AA alkaline batteries
Exterior dimensions	3" x 5" x 1"
Interior dimensions	3" x 8" x 2"
Backset compatibility	Universal latches and deadbolts fit 2-3/8" (60mm) or 2-3/4" (70mm)
Door thickness	1-3/8" (35 mm) to 1-3/4" (44 mm)
Keying	5-pin tumbler, C Keyway, 1 key included
Certifications	ANSI/BHMA A156.40-2015 Grade AAA; ANSI/BHMA A156.36-2010 Grade 1
Operating temperatures	Outside: -35°C to 66°C; Inside: -10°C to 49°C
Construction	High-quality metal with built-in alarm
Installation	No hardwiring; installs with screwdriver; Snap ’n Stay design
Warranty	Limited Lifetime mechanical/finish; 3-year electronics

---

Frequently Asked Questions (FAQ):

Q: Does this lock work without a smart hub?
A: Yes, it functions as a keypad deadbolt locally; remote control and integration require a Z‑Wave hub.

---

Q: How many codes can I program?
A: It supports up to 30 unique user codes plus a preset programming code.

---

Q: What door sizes does it fit?
A: Fits standard doors 1-3/8" to 1-3/4" thick with 2-3/8" or 2-3/4" backsets.

---

Q: What batteries are required and how long do they last?
A: Uses 4 AA alkaline batteries; typical use provides up to one year of battery life, with a low-battery indicator.

---

Q: Is there a warranty?
A: Limited lifetime mechanical and finish warranty with 3-year electronics warranty.

---

Classic Camelot trim meets modern smart security

The Camelot silhouette brings a timeless, tailored elegance to the entry, while the sleek touchscreen introduces a refined, contemporary edge. Its luminous keypad becomes a subtle jewel at the door, marrying heritage curves with future-forward tech. Pair it with polished brass hardware and a lacquered front door for a statement foyer. This lock is the finishing touch that elevates everyday living into quiet luxury.

---

Secure your home in style—add the Camelot Connect Smart Lock to your door today.
