Siemens 100 Amp Double-Pole 42kA Type QS Multi-Family Main Breaker
Regular price $249.30Siemens 100 Amp Double-Pole Main Breaker
The Siemens 100 Amp Double-Pole Main Breaker delivers powerful protection with a high 42kA interrupt rating, designed specifically for Siemens WMM and PAK multi-family metering lines. It's engineered to save time and space with a unique side-wired design, offering seamless integration into PowerMod and Uni-PAK residential meter stacks.
Key Features:
- Exclusive Design: Side-wired for efficient wiring and space-saving installation.
- High Interrupt Rating: Features a 42kA series rating for robust protection.
- Easy Installation: No costly filler plates required, fitting the same space as standard breakers.
- Flexible Compatibility: Accommodates #3-300kcmil Cu-Al Wire for varied connection options.
- Durability: UL listed and supported by a lifetime warranty for peace of mind.
Specifications Table:
| Specification | Details |
|---|---|
| AIC Rating | 42 |
| Breaker Type | Main Breaker |
| Connection Type | Non-Neutral |
| Interruption Type | Standard Trip |
| Maximum Amperage (A) | 100 A |
| Mounting Type | Plug-On |
| Number of Poles | Double |
| Pack Size | 1 |
| Product Weight (lb.) | 2.20 lb |
| Series Type | Not Specified |
| Trip Unit | Thermal Magnetic |
| Voltage (V) | 120/240 V |
| Certifications and Listings | UL Listed |
| Manufacturer Warranty | Lifetime |
| Product Depth (in.) | 8.66 in |
| Product Height (in.) | 2.75 in |
| Product Width (in.) | 5.90 in |
Frequently Asked Questions (FAQ):
Q: Can this breaker be used in commercial applications?
A: Yes, the Siemens 100 Amp Double-Pole Main Breaker is suitable for both residential and commercial applications, providing versatile use.
Q: What sizes of wire will this breaker accept?
A: This breaker accepts wire sizes from #3 to 300 kcmil Cu-Al, offering flexibility in installation.
Q: Is the breaker easy to install in PowerMod stacks?
A: Yes, the breaker integrates easily with Siemens PowerMod stacks, simplifying installation with its side-wired design and no requirement for filler plates.
Q: What is the benefit of the side-wired design?
A: The side-wired design saves wiring space in confined panels and eliminates difficult "S bends," streamlining the installation process.
Q: Does this breaker come with any certifications?
A: Yes, the Siemens 100 Amp Double-Pole Main Breaker is UL listed, ensuring compliance with safety standards.
Empower Your Space with Seamless Circuitry
The Siemens 100 Amp Double-Pole Main Breaker transforms electrical connectivity into an artful composition. The sleek side-wired design not only saves space but effortlessly brings a clean, efficient aesthetic to your electrical panel. Imagine the effortless choreography of meticulously managed power, where every breaker finds its place in harmony with the next. This breaker epitomizes seamless integration, ensuring that your dwelling remains not only functional but magnificently composed. For those who seek the finest in utility and design, this breaker is an essential addition to an advanced living space.
Upgrade your power system with the Siemens 100 Amp Double-Pole Main Breaker and experience the perfect balance of efficiency and elegance today.
