Leviton 15 Amp 125V Commercial Grade Tamper Resistant Duplex Outlet, White (R52-TCBR1-00W)
Regular price $3.7515A Tamper-Resistant Duplex Outlet, White
Commercial-grade duplex receptacle designed for safety and durability with tamper-resistant shutters. Rated 15A, 125V, NEMA 5-15R, it supports back and side wiring for flexible installation in residential or commercial spaces.
Key Features:
- Tamper-Resistant Safety: Mechanical shutter blocks foreign objects to help prevent shock injuries
- Commercial-Grade Durability: High-impact thermoplastic face/body; ultrasonically welded construction
- Flexible Wiring: Back and side wired with external clamps for visual verification; split-feed break-off tabs
- Self-Grounding: Staked clip stays secured for reliable grounding
- Clean Finish: White duplex style compatible with standard in-wall mounting; wall plate not included
Specifications Table:
| Specification | Details |
|---|---|
| Amperage | 15 A |
| Voltage | 125 V |
| NEMA Configuration | 5-15R |
| Receptacle Configuration | 5-15 |
| Number of Receptacles | 2 |
| Outlet Style | Duplex |
| Color/Finish | White |
| Color Family | White |
| Durability | Tamper Resistant |
| Grounding | Grounded |
| Indoor/Outdoor | Indoor |
| Material | Polycarbonate / High-impact thermoplastic |
| Mounting Type | In-Wall |
| Outlet Material | Thermoplastic |
| Package Quantity | 1 |
| USB Connection | Standard (no USB ports) |
| Wall Plate Included | No |
| Wire Connection Location | Side |
| Wire Connection Type | Screw Terminal; back and side wired with external clamps |
| Product Depth | 1.875 in |
| Product Height | 4.125 in |
| Product Width | 1.375 in |
| Certifications and Listings | cUL Listed |
| Manufacturer Warranty | 10 Year Limited |
| Safety Feature | Mechanical shutter mechanism prevents access to contacts |
| Construction | Ultrasonically welded; self-grounding clip staked on |
| Special Features | Break-off tabs for split feed; break-off plaster ears for flush alignment |
Frequently Asked Questions (FAQ):
Q: Is the wall plate included?
A: No, a wall plate is not included and must be purchased separately.
Q: What wiring methods are supported?
A: Supports back and side wiring with screw terminals and external clamps; split-feed conversion via break-off tabs.
Q: What is the electrical rating?
A: 15 Amp, 125 Volt, NEMA 5-15R, grounded.
Q: Is this outlet suitable for commercial installations?
A: Yes, it is a commercial-grade, tamper-resistant receptacle meeting NEC requirements for TR outlets.
Q: What materials is it made from?
A: Body and face are high-impact thermoplastic (polycarbonate/thermoplastic).
A Clean, Safe Essential for Modern Walls
This white duplex outlet brings crisp, understated polish to the room while quietly elevating safety with tamper-resistant shutters. The streamlined face and robust hardware feel purposeful—an elegant utility. Pair it with a matching screwless wall plate for a seamless, gallery-like finish. It’s a small upgrade that speaks volumes in a refined, well-appointed space.
Upgrade to Leviton’s tamper‑resistant commercial outlet today for a safer, cleaner look that installs with confidence.
