Hardware

Torrey Pines Venetian Bronze Low Profile Single Cylinder Entry Door Handleset w/ Torrey Door Lever ft SmartKey Security

Adjustable

$169.00 each

Orders start at $399. Combine any items to reach it.

  • Handing Universal
Quantity
1 item
$169.00
Standard delivery
$49.99 per order
Sales tax
Added at checkout

All orders are subject to approval.

You're not charged until your order is approved and ready to ship. Cancel free before then.

Standard delivery$49.99

Per order, added in your cart. We deliver to the 48 contiguous states.

Availability confirmed by the desk at approval, with your delivery date. Shipping policy · Returns

Hardware

Details & specifications.

From the maker · the maker’s description

The Prestige Series offers affordable luxury. It is our most accessible option available in retail stores across the nation; we know that just good isn't good enough to carry the Baldwin name. The Venetian Bronze finish is hand-rubbed to reveal unique bronze highlights and provides a rich and warm complement to the product's style.

  • Baldwin Prestige offers effortless, accessible style and luxury with superior security
  • Traditional inspired - low profile lock design shown in a venetian bronze finish
  • Lifetime mechanical and finish warranty
  • Featuring SmartKey Security, which protects against advanced break-in techniques and allows you to re-key your lock yourself in seconds.
  • Fits standard door preparations: 1-3/8 in. to 1-3/4 in. T
  • Universal lever fits both right handed and left handed doors
  • SmartKey Security re-key technology is compatible with Kwikset (KW1) keyway
SKU
305051208
Function
Handleset
Finish
Bronze
Backset
Adjustable
Style
Classic
Item Weight
10.6
Door Handing
Universal
Lock Type
Keyed
Features
Adjustable Backset, Kwikset SmartKey
Commercial/Residential
Residential
Total Number of Keys Included
2
Product Weight (lb.)
10.6
Keyway
KW1
Deadbolt Type
Single Cylinder Deadbolt
Minimum door thickness (in.)
1.75
Knob/lever strike
Round corner
Handleset Product Type
2 Piece Front & Back
Application Type
Entry
Lock Type2
Keyed Entry
Material
Metal
Keying Type
Keyed Different
Deadbolt strike
Round corner
Door Locks & Knobs Product Type
Keyed Handlesets
Interior/Exterior
Exterior
Lever style
Straight
Electronic/Mechanical
Mechanical
Included
Hardware, Installation Instructions
Outside bottom handle plate width (in.)
2.66
Outside bottom handle plate length (in.)
13.09
Deadbolt cross bore diameter (in.)
2.125
Deadbolt bore hole diameter (in.)
1
Knob/lever housing height (in.)
2.75
Outside top handle plate length (in.)
3.41
Outside key plate length (in.)
3.41
Deadbolt trim ring diameter (in.)
2.75
Knob/lever strike height (in.)
2.25
Knob/lever strike width (in.)
1
Assembled Depth (in.)
2.91 in
Projection (in.)
2.91
Outside top handle plate width (in.)
2.66
Outside key plate width (in.)
2.66
Assembled Height (in.)
17.75 in
Handle grip length (in.)
1
Assembled Width (in.)
2.66 in
Lever grip length (in.)
4.28
Inside top plate width (in.)
1
Maximum door thickness (in.)
2.25
Deadbolt strike height (in.)
2.25
Knob/lever housing width (in.)
2.75
Deadbolt strike width (in.)
1
Inside top plate length (in.)
1
Deadbolt throw length (in.)
1
Knob/lever throw length (in.)
.5
Knob/lever bore hole diameter (in.)
1
Knob/lever cross bore diameter (in.)
2.125
Manufacturer Warranty
Lifetime mechanical and finish warranty
Certifications and Listings
No Certifications or Listings

Specifications are provided by the manufacturer. Brand names are trademarks of their owners.

Guide

Door hardware, by function

  1. 1

    Passage

    No lock. Halls and closets.

  2. 2

    Privacy

    A push-button lock inside. Bedrooms and baths.

  3. 3

    Keyed entry

    Locks with a key from outside. Exterior and garage entry doors, often with a deadbolt.

  4. 4

    ANSI grade

    Grade 1 is the toughest, grade 3 the lightest residential grade.

  5. 5

    Cabinet pulls

    Sized by hole spacing, center to center. Match the holes you have.
