Heavy Duty Adjustable Door Closer, Dark Bronze

The NORTON DOOR CONTROLS Heavy Duty Door Closer is designed for both interior and exterior doors, offering versatile mounting options to meet diverse needs. This Grade 1, hydraulic closer ensures durability and smooth operation, and its dark bronze finish adds an elegant touch to any decor.

---

Key Features:

• Versatile Mounting: Can be used as standard, top frame, or parallel closer to suit any door swing or preference.
• Heavy Duty Performance: Supports doors up to 250 lbs, suitable for high-traffic areas with 25 million operation cycles.
• Durable Construction: Made from high-grade aluminum and finished in dark bronze for enhanced longevity and style.
• Fire Safety: UL and cUL Listed with a 3-hour fire rating, ensuring safety compliance.
• Non-Handed Design: Suitable for left or right-handed doors, making installation easy and flexible.

---

Specifications Table:

Specification	Details
Manufacturer Part Number	1601XBR
Brand	NORTON DOOR CONTROLS
Closer Mounting Type	Top Frame
Closer Series	1600
Closer Type	Non-Hold Open
Color	Dark Bronze
Compatible with Brand	NORTON RIXSON
Display Qty	1
Display Sell UOM	EA
Max Door Opening Angle	180 °
Features	1-3/8 in dia Piston
Finish	Bronze
Fire Rating	3 hr
Housing Depth	2-7/8 in
Housing Height	2-5/8 in
Energy Source	Hydraulic
Door Width Campatibility	48 in
Location Use	Interior/Exterior
Standards	UL and cUL Listed
UL Fire Rating	UL10C
Spring Type	Adjustable
Height Between Mounting Holes	3/4 in
Spring Size - Minimum	1
Material	Aluminum
Door Weight - Maximum	250 lb
Exterior Door Width - Maximum	48 in
Product Type	Door Closer
Projection	2-7/8 in
Spring Size	6
Arm Type	Regular
Closer Cycles	25,000,000
Hand Orientation	Non-Handed
Housing Length	9-3/4 in
Operation Style	Manual
Performance Duty Rating	1
Length Between Mounting Holes	9-1/16 in
Ligature Resistance	Not Ligature-Resistant
ADA Compliant	Yes
Performance Rating	Grade 1 - Heavy Duty
Finish C	Bronze ; Aluminum ; Dark Bronze

---

Frequently Asked Questions (FAQ):

Q: How do I choose the right mounting type?
A: The NORTON DOOR CONTROLS Door Closer is adjustable for standard, top frame, or parallel mounting, allowing you to choose based on door swing and aesthetic preference.

---

Q: Is this closer suitable for outdoor use?
A: Yes, it is designed for both interior and exterior doors, with materials and construction suited to withstand external environments.

---

Q: Can this door closer handle heavy-duty usage?
A: Absolutely, with a Grade 1 performance rating, it can handle extensive use in high-traffic areas, supporting doors up to 250 lbs.

---

Q: Does the color of the closer match common interior designs?
A: The dark bronze finish offers a classic and sophisticated look that complements a wide range of interior and exterior decors.

---

Q: What are the energy source and operation style of this door closer?
A: This door closer is hydraulic and operates manually, providing smooth and reliable door closing without an external power source.

---

Transforming Entryways with Timeless Elegance

Imagine every entrance to your space accented with the NORTON DOOR CONTROLS Heavy Duty Door Closer, draped in a rich dark bronze finish, echoing sophistication. Its sleek silhouette not only complements, but elevates the aesthetic harmony of door fixtures, blending effortlessly into historical and modern interiors alike. Envision it as a seamless transitional element—a whisper of mechanical precision as each door closes behind you, creating an inviting yet assured embrace of luxury living.

---

Upgrade your entryway with the NORTON heavy-duty door closer—experience smooth, elegant door operation today.
