M18 FORCE LOGIC Press Tool Kit with Jaws & SAWZALL

This Milwaukee M18 FORCE LOGIC press tool kit delivers portable, one-handed pressing for copper piping from 1/2 in. to 2 in. with up to 5,400 lbs of force. The brushless, cordless system includes multiple jaws, REDLINK intelligence for monitored force and connection indication, plus an M18 FUEL ONE-KEY SAWZALL and a 5.0Ah battery for productivity on the jobsite.

---

Key Features:

• Lightweight, One-Handed Operation: In-line design is the smallest and lightest in its class at 3.8 lbs for tight-space access
• Reliable Press Performance: Delivers up to 5,400 lbs of force with REDLINK monitoring and visual press indicator for verified connections
• Comprehensive Kit: Includes 1/2–2 in. M18 jaws, two M18 REDLITHIUM CP2.0 batteries, M18/M12 multi-voltage charger, hard case, plus M18 FUEL ONE-KEY SAWZALL and 5.0Ah battery
• Wide Compatibility: Part of the M18 system and compatible with all M18 batteries
• Warranty Coverage: 5-year tool warranty and 2-year jaw warranty

---

Specifications Table:

Specification	Details
System	M18
Power Type	Battery
Brushless Motor	Yes
Force Output	Up to 5,400 lbs
Tool Weight	3.8 lbs (press tool only); Product Weight 5.6 lb
Compatible Pipe Material	Copper
Compatible Pipe Sizes (included jaws)	1/2 in., 3/4 in., 1 in., 1-1/4 in., 1-1/2 in., 2 in.
Maximum Pipe Size Capacity	4 in.
Dimensions (Tool)	Depth 14.17 in.; Height 4.50 in.; Width 3.14 in.
Included Batteries	(2) M18 REDLITHIUM CP 2.0 (48-11-1820) and (1) M18 5.0Ah (48-11-1850)
Charger	M18 & M12 Multi-Voltage Charger (48-59-1812)
Additional Tool	M18 FUEL ONE-KEY SAWZALL Reciprocating Saw (2721-20)
Included Jaws	M18 1/2, 3/4, 1, 1-1/4, 1-1/2, 2 in. (49-16-2650 to 49-16-2655)
Warranty	5-year tool; 2-year jaw

---

Frequently Asked Questions (FAQ):

Q: What pipe materials is this press tool compatible with?
A: It is specified for copper piping with included jaws from 1/2 in. to 2 in.

---

Q: How does the tool confirm a proper press?
A: A visual press indicator provides assurance of a completed, quality connection and REDLINK monitors force output.

---

Q: What is included in the kit?
A: M18 FORCE LOGIC press tool (2773-20), jaws 1/2–2 in. (49-16-2650 through 49-16-2655), two M18 CP2.0 batteries (48-11-1820), M18/M12 multi-voltage charger (48-59-1812), hard case, M18 FUEL ONE-KEY SAWZALL (2721-20), and one M18 5.0Ah battery (48-11-1850).

---

Q: What is the maximum pipe size capacity?
A: Up to 4 in. maximum pipe size capacity; included jaws cover 1/2–2 in.

---

Q: Is it compatible with other M18 batteries?
A: Yes, it is compatible with all M18 batteries.

---

Precision Pressing Power, Refined

This compact press tool kit streamlines mechanical rooms and exposed runs with crisp, consistent connections. The sleek in-line body and intelligent press indicator feel modern and purposeful, turning a technical task into an elegant gesture. Pair its vivid Milwaukee red case with organized pipe racks and matte-black hangers for a refined utility aesthetic. It’s a polished, professional essential that elevates the craft and the space alike.

---

Equip your crew with verified, one-handed pressing and add this complete M18 FORCE LOGIC kit to your cart today.
