DHC 4-3 4.5 kW.68 GPM Point-of-Use Tankless Electric Water Heater

$175.17

/
Shipping calculated at checkout.
DHC tankless water heaters are ideal for residential and commercial point-of-use sink applications including: bathrooms, cabins and cottages, office buildings, stores, malls, warehouses, restaurants, and gas stations. They heat water instantaneously and endlessly at 99% efficiency as it flows through the unit. Because they do not store hot water like tank water heaters, they have no stand-by energy losses. Venting is not necessary and the compact European design can be installed with the unit visible. The hot water temperature delivered by a DHC depends on the incoming cold water temperature, the flow rate through the unit, and the size of the DHC model. They excel at supplying water at a constant temperature but the model must be carefully matched to the flow rate of the sink to operate properly. Refer to the DHC Sizing Guide to determine which model you need. Call Stiebel Eltron at 800.582.8423 with any questions. Stiebel Eltron invented tankless electric water heating technology more than 90 years ago, and is still the industry pioneer and world leader today, with an engineering and manufacturing tradition of excellence.
  • DHC 4-3 is designed to provide endless hot water at 99% efficiency in a 277-Volt commercial setting for 1 low or low/medium-flow lavatory sink in warm or cool climates
  • Requires 277-Volt electric service with 1 dedicated 20 Amp breaker and 12-Gauge copper wiring
  • Model must be carefully matched to the application in order to operate properly
  • Water connections are 1/2 in. NPT and should be detachable (such as braided steel flex connectors or isolation valves) to allow for easy servicing
  • Overheat safety protection and thermal protection reset are standard
  • Sleek European design is considerably smaller than a tank, saves space, and allows installation flexibility
  • Made in Germany
  • Professional installation recommended
  • Call Stiebel Eltron at 800.582.8423 with any sizing questions
  • 7-year leakage and 3-year parts residential and commercial warranty against defects in workmanship and materials under normal use
  • Stiebel DHC Sizing Guide:

    Stiebel DHC Sizing Guide



Features
Item Weight 4.6
Uniform Energy Factor 0
Product Weight (lb.) 4.6
Flow Rate @ 45 F Rise (gallons/min) 0.68
Heat Exchanger Warranty 7 Year
Flow Rate @ 55 F Rise (gallons/min) 0.56
Application Type Point of Use
Minimum Temperature (F) 0.0
Pack Size 1
Wattage (watts) 4500
Finish Family White
Returnable 180-Day
Amperage (amps) 17
Minimum Activation Rate (gpm) 0.42
Required Volt Connection 277 volt
Wattage (watts)2 4500
Maximum Temperature (F) 0.0
Water Heater Features Overheat Protection,Wall Mounted
Fuel Type Electric
Indoor/Outdoor Indoor
Flow Rate @ 35 F Rise (gallons/min) 0.88 gal (US)/min
Flow Rate @ 65 F Rise (gallons/min) 0.47
Water Connection Size (in.) 1/2” NPT
Product Width (in.) 7.875
Product Depth (in.) 4.125
Product Height (in.) 14.1875
Certifications and Listings CSA Listed,ETL Listed,UL Certified
Labor Warranty No Warranty
Part Warranty 3 Year
