Toro 570Z Pro Series 1/4-Circle Pop-Up Sprinkler
Regular price $5.811/4-circle pop-up sprinkler head for small coverage
The Toro 570Z Pro Series pop-up sprinkler delivers a precise 1/4-circle spray, ideal for medium-sized lawns and ground cover. Built with an ABS plastic head and stainless steel retraction spring, it offers durable, below-ground installation with efficient water distribution.
Key Features:
- Quarter-Circle Coverage: Fixed spray pattern up to 15 ft for targeted watering
- Durable Build: ABS plastic head with stainless steel retraction spring resists corrosion
- Water-Saving Design: Patented zero-flush seal and MPR nozzle promote even, efficient watering
- Easy Customization: Radius-reduction screw trims spray up to 25% and nozzle is replaceable
- Standard Connection: 1/2 in. female NPT inlet for simple in-ground installs
Specifications Table:
| Specification | Details |
|---|---|
| Sprinkler Head Type | Fixed |
| Sprinkler Head Spray Pattern | Quarter Radius (1/4-circle) |
| Sprinkler Type | Pop-Up |
| Irrigation System Component | Sprinkler |
| Inlet Size | 0.5 in |
| Thread Type | Female NPT |
| Inlet Type | Female |
| Mounting | In-ground install |
| Spray Distance (max) | 15 ft |
| Spray Distance (min) | 11.25 ft |
| Maximum Coverage Area | 15 sq ft |
| Maximum Gallons Per Minute | 1.23 GPM |
| Pressure Rating | 75 PSI |
| Sprinkler Angle | 28° (min/max) |
| Head Material | ABS Plastic |
| Nozzle Material | ABS Plastic |
| Color Family | Black |
| Riser | Riser not required |
| Product Height | 4.875 in |
| Product Width | 2.0625 in |
| Product Depth | 2.0625 in |
| Pack Size | 1 |
| Package Quantity | 1 |
| Manufacturer Warranty | 1 year |
| Descriptive Features | Zero-flush seal; stainless steel retraction spring; matched precipitation rate nozzle; radius reduction screw up to 25% |
Frequently Asked Questions (FAQ):
Q: What is the spray distance and pattern?
A: It provides a fixed 1/4-circle spray with a radius up to 15 ft (minimum about 11.25 ft).
Q: What inlet size does it use?
A: It has a 1/2 in. female NPT inlet.
Q: Is the nozzle replaceable?
A: Yes, the pre-installed MPR nozzle can be replaced with any compatible Toro nozzle.
Q: Does it help reduce water waste?
A: Yes, the zero-flush seal and matched precipitation rate nozzle help prevent water loss and ensure even distribution.
Q: What is the warranty?
A: Manufacturer warranty is 1 year.
Clean, Precise Hydration for a Polished Landscape
This compact pop-up head delivers disciplined quarter-circle coverage, sculpting lush borders with crisp, even spray. The streamlined black form and sturdy spring mechanism speak to enduring performance. Cluster along pathways or patio edges to frame green spaces with tailored symmetry. A discreet essential that elevates everyday outdoor luxury.
Upgrade your irrigation with Toro’s 570Z quarter-circle precision—add it to your system today for efficient, even coverage.
