Homeline 50A 2-Pole GFCI Breaker

This Square D Homeline 50 Amp two-pole GFCI circuit breaker provides overload, short-circuit, and Class A ground fault protection for 120/240V AC systems. Designed for quick plug-on installation in Homeline load centers and CSEDs, it delivers a 10 kA interrupt rating and reliable electronic trip performance.

---

Key Features:

• Comprehensive Protection: Combines overload, short-circuit, and Class A ground fault protection for branch circuits
• Homeline Compatibility: Plug-on design fits Homeline load centers and CSEDs using two spaces
• Residential Ready: Rated 120/240 VAC with 10,000 AIR for dependable home protection
• Durable Build: UL Listed and ANSI certified with electronic trip unit for consistent performance
• Easy Testing: Built-in test button simplifies periodic safety checks

Please check the Product Data Sheet Here

---

Specifications Table:

Specification	Details
Series	Homeline
Amperage	50 Amp
Poles	2-Pole (Double)
Interruption Type	GFCI, Class A
Voltage	120/240 VAC
AIC Rating	10,000 AIR
Mounting Type	Plug-On
Connection Type	Non-Neutral (with pigtail)
Trip Unit	Electronic
Pack Size	1
Certifications	UL Listed, ANSI Certified
Product Height	3.13 in
Product Width	2 in
Product Depth	2.98 in
Manufacturer Warranty	Limited lifetime when installed in a Homeline load center
Application	Residential/commercial branch circuit protection with ground-fault protection

---

Frequently Asked Questions (FAQ):

Q: Will this breaker fit my panel?
A: It is compatible only with Square D Homeline load centers and CSED devices that have two adjacent spaces available.

---

Q: What does Class A GFCI mean?
A: Class A trips when ground-fault current is 6 mA or more, providing personnel protection in areas like kitchens, garages, and outdoors.

---

Q: What voltage systems does it support?
A: It is rated for 120/240 VAC applications.

---

Q: What is the interrupt rating?
A: 10,000 AIR (AIC) at 120/240 VAC.

---

Q: Is it UL listed and does it have a warranty?
A: Yes, it is UL Listed and covered by a limited lifetime warranty when installed in a Homeline load center.

---

Streamlined Safety with Industrial Poise

This breaker brings refined utility to the backbone of your home, pairing crisp geometry with a purposeful black finish. The standout coiled pigtail feels sculptural while delivering vital GFCI protection. Tuck it into a Homeline panel to anchor spa circuits, kitchens, or workshops with quiet confidence. It’s an essential, elegant upgrade for a safer, more luxurious daily life.

---

AI Review Summary:

Overall sentiment is strongly positive. Customers praise reliable GFCI protection and easy plug-on installation in Homeline panels, often citing quick swaps and immediate restoration of protected service for spas and hot tubs. Build quality and brand trust are recurring themes; several note consistent performance and clear test functionality. A few report the breaker’s higher cost versus standard 2-pole units and occasional confusion verifying panel compatibility; rare reviews mention nuisance trips tied to downstream wiring faults rather than the breaker. Representative quotes: “Dropped right into my Homeline box and my spa was up in minutes,” “Pricey but worth it for true GFCI protection,” and “Worked perfectly once I corrected a wiring issue that caused tripping.”

---

Elevate your panel’s protection—add this Homeline 50A GFCI breaker to safeguard your circuits with proven Square D reliability.
